Versa Block Clamp AVBC-600

Overview

The Aardwolf AVBC-600 is a multi-purpose lifting clamp designed for handling concrete blocks, stone, drums, rubber tires, and various load shapes in construction and industrial environments.

With a 100–600 mm grip range and a 1200 kg working load limit (WLL), this adjustable block lifting clamp is suitable for medium-sized materials where flexibility and versatility are required.

Unlike single-purpose clamps, the AVBC-600 is engineered to adapt to different material types and shapes through its adjustable and reversible clamping system.

How It Works

The clamp is connected to a crane or lifting equipment via the central lifting eye.

The sliding clamp arms are adjusted to match the load size and secured using the cam lock mechanism to maintain proper positioning. When lifting begins, the gravity-controlled locking system automatically engages to secure the load.

Once the load is fully lowered, the clamp releases automatically, allowing for quick removal.

Key Features

• Flexible grip range (100–600 mm): Suitable for a wide range of material sizes
• Gravity-controlled automatic locking: Engages during lifting and releases after set-down
• Adjustable sliding clamp arms: Allows easy adaptation to different load dimensions
• Cam lock positioning system: Secures clamp arms firmly during operation
• Reversible clamp jaws (internal / external gripping): Enables handling from inside or outside the load
• High-friction rubber-lined pads (replaceable): Improve grip while helping protect load surfaces
• Heavy-duty steel construction: Designed for durability in construction and industrial use

Applications

• Handling concrete blocks, stone, and masonry units
• Lifting drums, rubber tires, and cylindrical objects
• Material handling in warehouses and construction sites
• Multi-purpose lifting across different load shapes

Usage Notes

• Ensure the load is fully seated within the clamp jaws before lifting
• Do not use on wet, oily, or contaminated surfaces
• Do not exceed the rated load capacity
• Lift only one load at a time
• Inspect clamp arms, pads, and locking mechanisms before use
• Keep clear of suspended loads at all times

Frequently Asked Questions

What materials can the AVBC-600 handle?

It is suitable for concrete blocks, stone, drums, rubber tires, and various load shapes within the rated capacity.

What makes the AVBC-600 different from other clamps?

The AVBC-600 features reversible clamp jaws (internal and external gripping) and an adjustable clamping range, allowing it to handle a wider variety of material sizes and shapes compared to standard clamps.

What ensures a stable and secure grip?

A secure grip depends on proper load positioning within the clamp jaws and clean, dry contact surfaces to maintain safe lifting performance.
