AVGLP Vacuum Glass Lifter AVGLP2-200

Overview

The AVGLP2-200 is a pneumatic vacuum glass lifter designed for lifting, tilting, and positioning glass, porcelain, and sheet materials in workshops and construction environments.

With a compact two-pad configuration, this vacuum lifter for small glass panels offers excellent manoeuvrability, making it ideal for confined spaces and precision handling tasks.

Powered by compressed air, the unit integrates an automatic vacuum system and a battery-powered safety alarm, ensuring reliable suction performance throughout the lifting process.

How It Works

The lifter uses compressed air to generate vacuum suction through two pads. Once placed on the glass surface, it creates a secure grip and maintains stable pressure during lifting.

The system supports pneumatic tilting from 0° to 90°, allowing smooth transition between horizontal and vertical positioning for installation tasks.

Key Features

• Compact dual pad vacuum glass lifter: Ideal for small to medium glass panels
• Pneumatic 0–90° tilting system: Enables flexible positioning during handling
• Automatic vacuum pumping system: Maintains suction if pressure drops
• Battery-powered safety alarm system: Provides visual and audio alerts when vacuum is unsafe
• Slide valve ON/OFF control: Allows quick attachment and release
• Durable steel construction: Suitable for workshop and on-site use

Applications

• Handling small to medium glass panels
• Interior glass installation
• Workshop glass processing
• Precision lifting tasks in confined spaces

Usage Notes

• Use only on clean, non-porous surfaces
• Do not exceed the rated working load
• Ensure full pad contact with the glass surface
• Always verify vacuum pressure before lifting

Frequently Asked Questions

When should you use a compact vacuum glass lifter?

A compact vacuum glass lifter like the AVGLP2-200 is ideal for handling smaller panels and working in tight or restricted spaces.

Is this vacuum lifter suitable for thin glass panels?

Yes, the vacuum lifter for glass panels provides controlled suction, making it suitable for handling various glass thicknesses.

How does the safety system work?

The unit combines a battery-powered alarm system with an automatic vacuum backup system to maintain grip and alert the operator if vacuum levels drop.
