อุปกรณ์ยกสุญญากาศระดับมืออาชีพ AVLP Pro AVLP1-250P

Overview

The AVLP1-250P is a pneumatic vacuum lifter for stone slabs, designed for precise lifting, tilting, and positioning in fabrication workshops and construction environments.

As part of the Pro series, it features an advanced control system with dual operating modes, a battery-powered safety system, and optimised air usage for efficient operation.

With its compact single-pad design, this vacuum lifter for small to medium stone slabs provides flexible handling while maintaining reliable suction performance.

How It Works

The lifter uses compressed air to generate vacuum suction through the pad. Once placed on the slab surface, it creates a secure grip and maintains stable pressure during lifting.

The system operates in two modes, automatically maintaining safe vacuum levels while allowing the operator to choose between continuous monitoring or energy-saving operation.

Key Features

• Dual operating modes vacuum lifter
  Switch between Audio Alarm Mode and Energy Saver Mode
• Integrated vacuum monitoring system
  Real-time pressure tracking with audio and visual alerts
• Battery-powered safety system (12V Li-ion)
  Ensures alarm functionality independent of air supply
• Pneumatic 0–90° tilting
  Enables smooth vertical and horizontal positioning
• Slide valve ON/OFF control
  Allows fast and efficient attachment and release
• Adjustable handles
  Improve ergonomics and operator control

Applications

• Handling small to medium stone slabs
• Stone fabrication and workshop operations
• Installation and positioning tasks on-site
• Warehouse and material handling environments

Usage Notes

• Use only on clean, smooth, non-porous surfaces
• Do not exceed the rated working load
• Always verify vacuum pressure before lifting
• Ensure full pad contact with the slab surface
• Do not operate if the safety system is not functioning

Frequently Asked Questions (FAQ)

What makes the AVLP Pro vacuum lifter different from standard models?

The Pro series includes a dual-mode vacuum lifter system, battery-powered safety alarms, and improved efficiency in maintaining vacuum pressure during operation.

How do the dual operating modes improve performance?

• Audio Alarm Mode: Provides continuous alerts when vacuum conditions are unsafe
• Energy Saver Mode: Automatically regulates air supply to maintain pressure while reducing air consumption

Why is a rotatable vacuum pad important in slab lifting?

A rotatable vacuum pad lifter allows better alignment with different slab shapes and sizes, improving suction contact and overall lifting stability.

How does the system support safe lifting operations?

The lifter uses a combination of real-time vacuum monitoring, audio-visual alarms, and a vacuum tank system to maintain stable suction and ensure safe handling conditions.
